TLS series Mining Watering Cart is a watering cart developed by Tonly with large water storage capacity, wide spraying range, long continuous spraying mileage and high operating efficiency.
Product
Features
Fire-fighting function:Equipped with 25m range water gun,it can be used as atemporary fire truck.
Greening function:The sprinkler system has a mixing function,which can mix pesticides and spray trees an green belts.
Suction pimp water function:It can suck water and store it to the water tank,and transport water for production operation.
Technical
Parameters
| Overall parameters | Model | TLS753 |
| Brang | Tonly | |
| Drive mode | 6*4 | |
| GVW (t) | 72 | |
| Rated payload(t) | 50 | |
| Kerb weight (t) | 22 | |
| Dimensions (mm) | 11295*3340*3965 | |
| Wheelbase (mm) | 5075+1550 | |
| Whell track (mm) | 2680/2500 | |
| Minimum ground clearance (mm) | 305 | |
| Minimum turning radius (m) | 12.6 | |
| Braking distance (m) | 12 | |
| Maximum climbing degree (％) | ≥32 | |
| Maximum speed (km/h) | 40 | |
| Engine | Model | WP12G430E310 |
| Manufacturer/Country | Weichai/China | |
| Power (hp/kw) | 430/316 | |
| Transmission | Model | 7DS180 |
| Manufacturer/Country | Fast/China | |
| Input torque (N•m) | 1800 | |
| Axle | Manufacturer/Country | Hande/China |
| Load/T | 20+35+35 | |
| Tires/Rims | Tire model | 14.00-25 |
| Rim size | 10.0/2.0-25 | |
| Water Pump | Model | 80QZB60/90S |
| Manufacturer/Country | Hangzhou Weilong/China | |
| Tank | Inner cavity size (mm) | 8100*3250*2200 |
| Plate thickness | Tank body 6mm;wave stopper 6mm (6pieces) | |
| Material | Q355B (optional stainless steel material) |
