This dump truck is equipped with an electronically controlled engine and an automatic transmission,with more convenient control and higher efficiency; Large tonnage engineering axlesas well as engineering-specific tires and a 45CBM large volume container with large load capacity.
Adopt the whole machine optimization design scheme of Tonly core technology,with stable performance,reliable quality and attendance rate of above 90%.
TL897 Mining Dump Truck
Technical Parameters
Overall parameters | Model | TL897 |
Brand | Tonly | |
Drive mode | 6×4 | |
GVW (t) | 135 | |
Rated payload (t) | 90 | |
Kerb weight (t) | 45 | |
Dimensions (mm) |
10180×3950×4420 |
|
Wheelbase (mm) | 4175+1900 | |
Wheel track (mm) |
3100/2850 |
|
Minimum ground clearance (mm) | 410 | |
Minimum turning radius (m) | 12 | |
Maximum height of bucket lift (mm) |
9380 |
|
Maximum angle of bucket lift (°) | 48 | |
Loading height (mm) | 4020 | |
Braking distance (m) | 18 | |
Maximum climbing degree (%) | 30 | |
Maximum speed (km/h) | 45 | |
Engine | Model | QSM15-770-30 |
Manufacturer / Country | DCEC/China | |
Power (hp/kw) | 770/566 | |
Transmission | Model |
8DS280/with hydraulic clutch |
Manufacturer / Country | Fast/China | |
Input torque (N·m) | 2100 | |
Axle | Manufacturer / Country | Hande/China |
Load/T | 30+50+50 | |
Tires / Rims | Tire model | 480/95R29 |
Rim size | 13.00/2.5-29 | |
Container | Base plate material/thickness (mm) | NM400/16 |
Rear plate material/thickness (mm) | NM400/12 | |
Front plate material/thickness (mm) | T700/12 | |
Side plate material/thickness (mm) | T700/10 | |
Container volume (m³) | 45 | |
Hydraulic system | Model | FEA214 |
Manufacturer / Country | HYVA/China | |
Steering device | Hydraulic steering | |
Lifting time (s) | 24 | |
Discharge time (s) | 24 | |
Weight distribution | Empty load | |
Front axle (kg) | 15000 | |
Rear axle (kg) | 30000 | |
Total weight (50% fuel) (kg) | 45000 | |
Loaded | ||
Front axle (kg) | 30000 | |
Rear axle (kg) | 105000 | |
Total weight (kg) | 135000 |
